Atlas Copco XC4003 Diagnostic and Measurement | Engine Error Codes

In this video, we’ll show you the step by step instructions how to retrieve engine fault codes on an XC4003 compressor controller. Starting from the main screen, you'll learn the steps to finding engine error codes on your machine.

Watch the how-to video below and follow along these steps:

- To begin press the middle button on the left-hand side of the screen.

- Press enter to go into general settings, scroll down to eleven sixty for diagnostics and press enter

- Press enter again,

- Press the down arrow

- Press enter

- Press X to exit.

- We are showing a fault, so press the diagnostic button on the bottom left-hand side of the screen.

- Press the down Arrow to the DM 1 list and press enter.

- It shows a SPN 100 FMI 3 engine oil pressure alarm.

- Make the repair.

- After the alarm clears press the middle button on the left-hand side of the screen.

- Press enter to go into general settings and scroll down to eleven sixty and press enter

- Press enter again

- Press up to turn off diagnostics and press enter.

- Press X to return to the main screen.

- Press enter to clear the code,

- You are now ready to start.
